Item

Code

Description

1 Company code

C

Company code

2 Product name

J

Inductive proximity sensor

3 Shape of shell

Y

Cylinder-shaped

4 Dimension code

18

18=M18

5 Product type

S

Long-range type

6 Detection distance

15

15=15mm

7 Output mode

K

AC 2wires

L

DC 2wires

P

PNP 3wires

N

NPN 3wires

8 Output state

A

NO

B

NC

C

NO+NC

9 Connection

Without

Without: Lead wire

T

Plug-in

R

Wiring leads Plug-in

Model

CJY08S-1.5NA

CJY08S-1.5NB

CJY08S-1.5PA

CJY08S-1.5PB

CJY08S-03NA

CJY08S-03NB

CJY08S-03PA

CJY08S-03PB

CJY12S-04NA

CJY12S-04NB

CJY12S-04NC

CJY12S-04PA

CJY12S-04PB

CJY12S-04PC

CJY12S-07NA

CJY12S-07NB

CJY12S-07NC

CJY12S-07PA

CJY12S-07PB

CJY12S-07PC

CJY18S-10NA

CJY18S-10NB

CJY18S-10NC

CJY18S-10PA

CJY18S-10PB

CJY18S-10PC

CJY18S-15NA

CJY18S-15NB

CJY18S-15NC

CJY18S-15PA

CJY18S-15PB

CJY18S-15PC

CJY30S-17NA

CJY30S-17NB

CJY30S-17NC

CJY30S-17PA

CJY30S-17PB

CJY30S-17PC

CJY30S-25NA

CJY30S-25NB

CJY30S-25NC

CJY30S-25PA

CJY30S-25PB

CJY30S-25PC

Sensing

distance

1.5mm

3mm

4mm

7mm

10mm

15mm

17mm

25mm

Hysteresis

Max. 10% of sensing distance

Standard

 sensing

target

8×8

×1mm
( Iron)

8×8

×1mm
( Iron)

12×12

×1mm
( Iron)

25×25

×1mm
( Iron)

20×20

×1mm
( Iron)

40×40

×1mm
( Iron)

45×45

×1mm
( Iron)

75×75

×1mm
( Iron)

Setting

distance

0~1.8mm

0~3.5mm

0~3.5mm

0~6.5mm

0~8.5mm

0~13.5mm

0~18.5mm

0~28.5mm

Power supply

(Operating

voltage)

12-24VDC (10-30VDC)

Leakage

 current

Max.10mA

Response

Frequency

 (※1)

450Hz

400Hz

400Hz

300Hz

300Hz

200Hz

100Hz

100Hz

Residual

 voltage

(※2)

Max. 1V

Affection

by Temp.

Max. ±10% for sensing distance at ambient temperature 20℃

Control

output

Max. 200mA

Insulation

 resistance

Min. 50MΩ(at 500VDC megger)

Dielectric

strength

1500VAC 50/60Hz for 1minute

Vibration

1mm amplitude at frequency of 10 to 55Hz(for 1 min.) in each of X, Y, Z directions for 2 hours

Shock

500m/s2(approx. 50G) X, Y, Z directions for 3 times

Indicator

Operation indicator(red LED)

Ambient

temperature

-25~+70℃ ( No icing)

Storage

temperature

-30~+80℃ ( No icing)

Ambient

humidity

35~95%RH (No condensation)

Protection

circuit

Surge protection circuit, Reverse polarity protection circuit, Overcurrent protection circuit

Material

Case/Nut: Nickel plated Brass,

Washer: Nickel plated Iron,

 Sensing surface: PBT, Standard
cable(Gray): Polyvinyl chloride(PVC),

Oil resistant cable(Black): Oil resistant Polyvinyl chloride(PVC)

Cable

φ2.8, 3P, 2m

φ3.8, 3P,4P 2m

φ4.8, 3P,4P 2m

(AWG22, Core diameter: 0.1mm,

Number of cores: 22,
Insulator diameter: φ1.25)

(AWG22, Core diameter: 0.1mm,

Number of cores: 25,
Insulator diameter: φ1.25)

(AWG22, Core diameter: 0.1mm,

Number of cores: 30,

Insulator diameter: φ1.25)

Protection

IP67

Mutual-interference

When several proximity sensors are mounted close to one another a

malfunction of the sensor may be caused due to mutual interference.

Therefore, be sure to provide a minimum distance between the two

sensors as below chart indicates.

Influence by surrounding metals

When sensors are mounted on metallic panel, you must prevent the

sensors from being affected by any metallic object except target.

Therefore, be sure to provide a minimum distance as below chart

indicates.

Model
Item

CJY08S-1.5

CJY08S-03

CJY12S-04

CJY12S-07

CJY18S-10

CJY18S-15

CJY30S-17

CJY30S-25

A

9

12

24

48

42

84

90

150

B

16

24

24

36

36

54

60

90

e

0

8

0

11

0

14

0

15

φd

8

24

12

36

18

54

30

90

m

4.5

6

12

24

21

42

45

75

n

12

24

18

36

27

54

45

90
